ATM Series SF01 (Snap-Fit Caps)

Available in 2, 3, 4, 6, 8 and 12 positions

Amphenol Sine Systems’ ATM Series™ SF01 connectors are a high-performance, thermoplastic, cost-effective solution which features an integrated Snap-Fit Cap enhancement that ensures rear seal stability under uncontrolled, harsh environmental conditions, all while maintaining an IP68/69K rated (in mated condition) performance regardless of wire bundle direction or improper installation.

The ATM Series™ SF01 meets all the performance criteria and specifications of the original ATM Series™, is available in a wide variety of custom colors, and accepts all A Series™ Size 20 contacts. Required wedgelock sold seperately.

Key Features

A more robust end cap design incorporated onto the rear of the connector body where the seals are exposed
Enhanced Sealing Plugs for simplified insertion/removal, improved retention capabilities and include a positive ‘stop’ for full insertion verification
Thermoplastic housing with excellent UV resistance
Wedgelocks ensure proper contact alignment & retention
Integrated latch for mating ensures a secure connection
Superior front and rear environmental sealing
Compatible with existing standard products industry-wide
Custom color housing options available
