Environmentally-Sealed, Multi-Pin,
Heavy Duty, Circular Connectors
|
|
|
|
|
| Available in AHDP (Plastic) or AHDM (Metal) options
|
|
|
|
|
Amphenol Sine Systems’ DuraMate™ Family of environmentally-sealed, multi-pin, heavy duty, plastic (AHDP) or metal (AHDM/AHDBM) circular connectors provide an economical, quick-connect, bayonet-locking system manufactured to withstand the challenges and complexities of harsh-environment, off-road applications.
Our ISOBUS products specifically meet ISO 11783 standards (for control and communications between tractors, implements and software) for agricultural applications.
|
|
|
Key Features
- 3 key-way bayonet design ensures proper mating of connectors
- High density signal and mixed power insert configurations
- Operating temperature range: -55°C to +125°C
- High current configurations incorporating revolutionary
RADSOK® contacts
- High strength impact resistant & lightweight thermoplastic or zinc-alloy metal housings
- Low insertion force stamped terminals offer improved manufacturing efficiencies
- Environmentally-sealed and engineered rapid and secure mating system achieves IP68/IP69K protection (in mated condition) from ingress of dust, water, mud and other contaminants and is vibration resistent
- Sealing features consisting of durable high temperature silicone provide barrier from lubricating oils, hydraulic fluids and fossil fuels
- Backshells maintain a compression-fit design to resist maximum pull-out forces and facilitate strain-relief for jacketed cable ranges
- Utilizes A Series™ standard contact system (Stamped & Formed or Machined)
- Wire entry sealing available in three separate ranges for discrete wire applications
- Wide Thread Adapters (WTA) provide an enhanced threading for use with our wide variety of screw-on or clamshell backshells (AHDP Only)
- Smooth Ring Adapters (SRA) are designed for use without backshells for a smaller footprint (AHDP
Only)
- Backshell Ring Adapters (BRA) allow for use with other compatible industry-standard snap-on backshells (AHDP Only)
|
|
|
Applications: Harsh Environment, Off-Road
and Agricultural applications
|
|
|
|
|
|
|
|
|
Available in the following Series:
DuraMate™ AHDP (Plastic)- Size 18 with 8 insert arrangements 2, 6, 8, 14(x3), 20 and
21
- Size 24 with 13 insert arrangements 7(x2), 9, 16, 18, 19, 21, 23, 27, 29, 31, 35 and 47
DuraMate™ AHDP ISOBUS 91 Series (Plastic)
DuraMate™ AHDM (Metal)- Size 18 with 6 insert arrangements 2, 6, 8, 14, 20 and 21
- Size 24 with 13 insert arrangements 7(x2), 9, 16, 18, 19, 21, 23, 27, 29, 31, 35 and 47
DuraMate™ AHDM/AHDBM ISOBUS 91 Series (Metal)
|
|
|
|
|
|
|
|
|
|
|
